YG 15MASINGLE 15" MULTIFUNCTIONAL ACTIVE FULLRANGE SPEAKER

  • YG 15MA

 Frequency Response
 65 Hz ~ 20kHz (±3 dB )
 45Hz ~ 20kHz (-10dB )
 Power Rating Hi:60W, Fullrange:500W
 Impedance Hi:8Ω, Fullrange:3Ω
 Max. SPL124dB SPL,130dB SPL peak
 Drivers
 Hi:1.75"Ferrite compression diver
 Low:15" (75mm voice coil), Ferrite
 Dimensions (H x W x D) 666×426×380(mm)
 Weight 30kg
 Riggings M8 points
 Enclosure 15mm,18mm multilayer plywood
 Finish Black polyurethane paint
 Grille black steel mesh + acoustic transparent cloth
 Single Channel Class D Switching Power Amplifier Module@4Ω 700W
 Total Harmonic Distortion (1Khz, Full Power 4Ω) ≤0.5%
 SNR 101.5dB
 AUDIO IN Gain(1KHz 8Ω 30dB
 MIC IN Gain(1KHz 8Ω) 52dB
 Input XLR Input (Audio in/Mic in)
 Input Impedance 20K Ω balanced / 10K Ω unbalanced
 Output Circuit Type Class D
 DSP Built-in DSP
 Voltage Requirements 100V-120VAC/200-240VAC~50-60Hz
